Powerful SBC with Wireless, Dual GbEth, and Audio/Video I/OLifecycle: Fully Developed | Released: March 2017 | Guaranteed Availability: 2027 | RoHS Compliant
Powered by the NXP i.MX6 with the Arm® Cortex®-A9 core and features high performance components, connectivity, and multimedia capabilities.
- Robust Embedded Solution Providing Connectivity via WiFi+BT, Dual GbEth
- Full Featured Multimedia Solution with HDMI, LVDS, and Audio I/O
- Flexible Data Storage: High Reliability pSLC or High Capacity MLC eMMC Flash
- Practical Interfaces like SATA II, MiniCard, DIO, ADC, ModBus, USB, CAN
- Power Saving Design Sips < 3 W Typical and ~15 mW in Sleep Mode
No minimum order quantity on standard products.
- Block Diagram
- Related Products
- Parts & Accessories
Fully Connected Multimedia Powerhouse
Powered by the NXP i.MX6 SOC with the Arm® Cortex®-A9 core, the TS-7970 industrial Single Board Computer (SBC) stands out from the crowd with its high performance components, connectivity options, and multimedia capabilities. It's a general purpose, low-power SBC ready to tackle demanding applications including digital signage, HMIs, data acquisition, IoT, industrial automation, and anything in between.
Robust and Rugged Engineering
Each component on the TS-7970 has been carefully chosen to ensure reliable operation in the field. Solid connectors, such as the screw terminal block for power and I/O, securely snap in and hold on. Data is reliably stored in the onboard eMMC flash, configurable as pSLC for further reliability or MLC for more capacity. The fanless design of the TS-7970 paired with the low cost enclosure is able to withstand high vibration, high debris, and a wide temperature range of -40 °C - 85 °C (-20 °C to 70 °C for quad core).
Short Time to Market with Long Term Deployment
A productive out-of-the-box experience includes pre-installed Linux OS, development tools, and utilities for controlling DIO, UARTS, CAN bus, and more. The development kit makes sure you have all the necessary connections and cables to get off the ground quickly. The guaranteed 10+ year lifecycle ensures a long-term deployment in the field, free from expensive replacements that come from short, disposable lifecycles which are all too common.
The TS-7970 single board computer features high performance hardware in a small, enclosable footprint, featuring:
- NXP i.MX6 800 MHz Solo or 1 GHz Quad Core Arm based CPU
- 1 to 2 GB DDR3 RAM
- 4 GB MLC eMMC Flash, configurable as 2 GB pSLC for added reliability
- Wireless 802.11b/g/n and Bluetooth 2.1+EDR (4.0 BLE) onboard module
- Dual Gigabit Ethernet ports
- LVDS video output
- HDMI video output
- 1x microSD Card Socket
- Audio codec with headphone and microphone jack
Industry standard connectors, such as USB host and device ports, dual Gigabit Ethernet, RS-232 serial port, and rugged screw terminals are included. Additional storage or boot image is possible through the microSD socket. A temperature compensated (TCXO), battery-backed real time clock (BBRTC) keeps accurate time for the system and a watchdog timer is there to help when a system becomes unresponsive in the field.
The TS-7970 features popular I/O and interfaces, including:
- 1x MiniCard Socket (mini PCIe Form Factor using USB)
- 1x Two Wire Modbus (RJ45)
- 1x microSD Card Socket
- 1x SATA II (Quad core only)
- 4x USB Host Ports
- 1x USB Device Port (Console or OTG)
- 3x RS-232
- 1x TTL UART (Add 3 more without Bluetooth and RS-485)
- 2x RS-485
- 2x CAN Bus
- 32x GPIO
- 2x 30 VDC Tolerant DIO
- 3x Analog Input (4 - 20 mA)
- 1x PWM (3x with Custom FPGA Load)
Applications with strict low power requirements will appreciate the work that's been done to reduce power consumption to less than 3 watts in typical conditions and 15 mW sleep mode.
We've preloaded most everything you need to get your application up and running quickly, from utilities to read, write, and control the various interfaces to power management tools. Development can be done on the device itself using preloaded GNU development tools such as GCC and GDB. Linux GUI development can be done using QT, GTK, and more. Furthermore, development can be done using familiar and easily installed interpreted languages such as Python, Java, C# (Mono), etc. In keeping with an open source vision, we have the source code, toolchains, and binaries freely available for download from the TS-7970 Files Repository and Github page.
The TS-7970 offers an operating system choice of Yocto, Debian, Ubuntu, Ubuntu Core, Android™, or QNX® Neutrino® RTOS thanks in part to the well equipped U-Boot bootloader which can boot from eMMC flash or microSD card.
The TS-7970 ships with Debain 10 Buster. Debian 11 Bullseye is now supported on all of our i.MX6 products, including the TS-7970. Images, drivers, and toolchains are available for download. For more information, visit the Debian section of the manual.
By default, Debian 10 Buster is loaded which provides a massive repository of prebuilt applications and services and Debian provides a long history of focus on stability and support.
Yocto is also available to take full advantage of the i.MX6 GPU providing simple integration with QT Creator and IDEs for rapid development. The Yocto environment is a powerful, stable, and familiar software stack, including common Linux tools and interpreters. With Yocto, we provide an x86/x86_64 cross toolchain which supports common onboard libraries and integrates with QT Creator, and other IDEs.
Ubuntu Core is a tiny, transactional version of Ubuntu for IoT devices and large container deployments. It runs a new breed of super-secure, remotely upgradeable Linux app packages known as snaps - and it's trusted by leading IoT players, from chipset vendors to device makers and system integrators.
The world's most popular mobile OS, now available on a robust embedded system. Android™ provides power development tools and a large community of developers. Android™ Nougat 7.1.1 is available for the TS-7970. The distribution provided for the TS-7970 includes driver support for all of the available hardware interfaces, including many not available in the standard Android™ distributions.
The QNX® Neutrino® RTOS is a full-featured and robust OS that scales down to meet the constrained resource requirements of realtime embedded systems. It is a true microkernel design and its modular architecture enable customers to create highly optimized and reliable systems with low total cost of ownership.
- U-Boot Bootloader
- Linux Kernel 4.1
- Android™ Nougat 7.1.1
- QNX® Neutrino® RTOS
- Yocto, Debian Buster, and Ubuntu 16.04 distribution and Ubuntu Core support
- Flexible programming language support
- Source code examples available
- Linux GUI development using QT, GTK, and more
Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.
Arm and Cortex are registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
QNX® and Neutrino® are registered trademarks of QNX Software Systems Ltd. in certain jurisdictions.
Android is a trademark of Google LLC.
embeddedTS provides complete documentation for our mature products, including manuals, schematics, mechanical drawings, etc. The most recent documentation files are always made available through our website. If you don't find the documentation you are looking for, contact support for more information. Also, please make sure to visit our Embedded Systems Support webpage, and our official documentation.
- TS-7970 REACH Certificate
- TS-7970 RoHS2 Certificate
- TS-7970 China RoHS Certificate
- TS-7970 FCC Compliance Testing Report
- TS-7970 MTBF Report
- Development Baseplate and Accessories for 3D Printing
- TS-7970 Linux Files Repository
- TS-7970 Utilities Git Repository
- TS-7970 i.MX6 Powered Single Board Computer Now Sampling
- Unveiling the TS-7970, a Powerful New i.MX6 Single Board Computer
- Bringing Ubuntu Core to the i.MX6 based TS-7970
Third Party Documentation
From the Blog:
|CPU Speed||1.1 GHz|
|Floating Point Unit||Yes|
|CPU Cores (Max)||4x|
|Base Memory Capacity||1 GB|
|Maximum Memory Capacity||2 GB|
|Base Flash Capacity||4 GB (2 GB SLC or 4 GB MLC)|
|microSD Card Socket||1x|
|SATA Ports||1x (mSATA; Quad Core Only)|
|Battery-Backed Real Time Clock||1x|
|Mean Time Between Failures||2275723 (MTBF Report)|
|Graphics Processing Unit||Yes|
|General-Purpose Input/Output (GPIO) Pins||34x (2x 30V; 32x 3.3V)|
|PWM Ports||1x (3x w/ Custom FPGA; Please contact us for more details)|
|Analog to Digital Ports (ADC)||3x (4 - 20 mA)|
|TTL-Level UART Ports||1x (Add 3x w/o RS-485/Bluetooth)|
|USB Host Ports||4x|
|USB Device Ports||1x|
|Precision Time Protocol (PTP)||Yes|
|Gigabit Ethernet Ports||2x|
|Operating Supply Voltage||5 VDC or 8 to 28 VDC|
|Fanless Temperature Range||-40 °C to 85 °C (-20 °C to 70 °C with Quad Core)|
|Graphics / HMI|
|HDMI Display Port||1x|
|Cellular Modem||Yes (via MiniCard Socket interface; Special order only, MOQ 100)|
|Bluetooth||Yes (4.0 BLE)|
|WiFi Radio / Wireless LAN||Yes (802.11b/g/n)|
|Linux Kernel Version||4.1|
|Debian Linux||Jessie (8.11)|
|Ubuntu Linux||16.04 Xenial Xerus|
|Android OS||7.1.1 Nougat|
|Yocto Linux||2.2 Morty|
|QNX Neutrino RTOS||Neutrino RTOS (Available on Quad Core Only)|
TS-7970 Block Diagram
embeddedTS can provide you with a custom tailored version of our standard product starting at minimum order sizes of 100 units or more. Customized products can be based on various combinations of many of the standard product features. There will be a one-time customization fee to cover the set up of your custom part number and production processes. Once the set up is complete the standard lead time for your customized product would be 6-8 weeks. Please contact us to get started on tailoring this product to meet your needs. In addition to tailoring our standard product to your needs, for slightly larger orders sizes, embeddedTS can also provide a custom design based on this product to meet your mechanical requirements or to add features.
In addition to tailoring features available in our standard product set, the following options are available:
|Product Option||Qty. 100 Price|
|SATA (Standard 7 Pin Connector)||$4|
|3 Axis Gyro-Accelerometer||$12|
|SIM Card Connector for Mini-Card Cellular Modems||$2|
|8 GByte Industrial Temperature eMMC||$13|
|16 GByte Industrial Temperature eMMC||$31|
|32 GByte Industrial Temperature eMMC||$53|
|64 GByte Industrial Temperature eMMC||$80|
Low cost plastic enclosure for the TS-7970-1G-4GF-S8S-RTC-I, TS-7970-2G-4GF-Q10S-RTC-E
Low cost plastic enclosure for the TS-7970-1G-4GF-S8S-RTC-CP-WIFI-I, TS-7970-2G-4GF-Q10S-RTC-CP-WIFI-E
Low cost plastic enclosure with WiFi Antenna for the TS-7970-1G-4GF-S8S-RTC-CP-WIFI-I, TS-7970-2G-4GF-Q10S-RTC-CP-WIFI-E
|TS-7970-2G-4GF-Q10S-RTC-E||TS-7970 extended grade (-20C to 70C) SBC with quad 1GHz i.MX6 CPU, 2GB RAM, 4GB eMMC, 1xGb-Eth, BB-RTC, microSD socket||Pricing|
|TS-7970-1G-4GF-S8S-RTC-I||TS-7970 industrial grade (-40C to 85C) SBC with solo 800MHz i.MX6 CPU, 1GB RAM, 4GB eMMC, 1xGb-Eth, BB-RTC, microSD socket||Pricing|
|TS-7970-2G-4GF-Q10S-RTC-CP-WIFI-E||TS-7970 extended grade (-20C to 70C) SBC with quad 1GHz i.MX6 CPU, 2GB RAM, 4GB eMMC, BB-RTC, 2nd Gb-Eth, audio in/out, microSD socket & mSATA, WiFi/BT (CB-ANT-TIWI antenna not included and is required for WiFi feature)||Pricing|
|TS-7970-1G-4GF-S8S-RTC-CP-WIFI-I||TS-7970 industrial grade (-40C to 85C) SBC with solo 800MHz i.MX6 CPU, 1GB RAM, 4GB eMMC, BB-RTC, 2nd Gb-Eth, audio in/out, microSD socket, WiFi/BT (CB-ANT-TIWI antenna not included and is required for WiFi feature)||Pricing|
|MSD-8GB-CLASS10-79XX||TS-7970/TS-TPC-7990 bootable 8GB Class 10 microSD card pre-loaded with Debian||$28|
|MSD-8GB-CLASS10-USB-79XX||TS-7970/TS-TPC-7990 bootable 8GB Class 10 microSD card pre-loaded with Debian, includes USB reader||$59|
|MSD-8GB-BLANK||8GB Class 10 microSD card||$28|
|PS-12VDC-REG-2_5AMP-8PB||Regulated 12 VDC, 2.5 A wall mounted power supply with 8 pin black connector (100-240 VAC, 50-60 Hz, A-type Plug)||$19|
|TS-ENC797-DIN||Low cost plastic enclosure with DIN Clip for the TS-7970-1G-4GF-S8S-RTC-I, TS-7970-2G-4GF-Q10S-RTC-E||$35|
|TS-ENC797-CP-DIN||Low cost plastic enclosure with DIN Clip for the TS-7970-1G-4GF-S8S-RTC-CP-WIFI-I, TS-7970-2G-4GF-Q10S-RTC-CP-WIFI-E||$35|
|TS-ENC797-CP-WIFI-DIN||Low cost plastic enclosure with WiFi Antenna and DIN Clip for the TS-7970-1G-4GF-S8S-RTC-CP-WIFI-I, TS-7970-2G-4GF-Q10S-RTC-CP-WIFI-E||$49|
|TS-ENC797||Low cost plastic enclosure for the TS-7970-1G-4GF-S8S-RTC-I, TS-7970-2G-4GF-Q10S-RTC-E||$28|
|TS-ENC797-CP||Low cost plastic enclosure for the TS-7970-1G-4GF-S8S-RTC-CP-WIFI-I, TS-7970-2G-4GF-Q10S-RTC-CP-WIFI-E||$28|
|TS-ENC797-CP-WIFI||Low cost plastic enclosure with WiFi Antenna for the TS-7970-1G-4GF-S8S-RTC-CP-WIFI-I, TS-7970-2G-4GF-Q10S-RTC-CP-WIFI-E||$43|
Development kit including suggested parts for new development
Includes packaged parts:
|CPU Arch||NXP i.MX6 Arm Cortex-A9|
|CPU Speed||800 MHz||1 GHz|
|RAM||1 GByte||2 GByte|
|Onboard Storage||4 GB MLC eMMC Flash|
|SATA Port||--||--||--||mSATA Socket (Shared with MiniCard)|
|MiniCard||--||miniPCIe Form Factor using USB||--||miniPCIe Form Factor using USB|
|Wireless||--||Wireless 802.11b/g/n and Bluetooth 4.0+EDR||--||Wireless 802.11b/g/n and Bluetooth 4.0+EDR|
|USB Host||4x USB 2.0|
|USB OTG||1x (Overlaps with USB Console)|
|Video||HDMI and Header with LVDS|
|Audio||Over HDMI Only||Stereo Codec with headphone and microphone jack & over HDMI||Over HDMI Only||Stereo Codec with headphone and microphone jack & over HDMI|
|Common Interfaces||1x Two Wire Modbus (RJ45), 2x RS-232, 2x RS-485, 2x CAN Bus, 32x GPIO, 2x 30 VDC Tolerant DIO, 3x Analog Input (4 - 20 mA)|
|Operating Temperature||-40 °C to 85 °C||-20 °C to 70 °C|
|Standard OS||Linux Debian Jessie 4.1.15 Kernel|
