Development Platform Combination Product
| CPU |
| Architecture |
Arm |
| Part Number |
i.MX 6UltraLite |
| Vendor |
NXP |
| CPU Speed |
696 MHz |
| Floating Point Unit |
Yes |
| CPU Cores (Max) |
1x |
| Core Specs |
| Base Memory Capacity |
512 MB |
| Maximum Memory Capacity |
1 GB |
| FPGA |
4 k LUT |
| Watchdog Timer |
1x |
| Storage |
| Base Flash Capacity |
4 GB |
| Flash Type |
eMMC |
| microSD Card Socket |
1x |
| General I/O |
| General-Purpose Input/Output (GPIO) Pins |
46x |
| PWM Ports |
8x |
| Analog to Digital Ports (ADC) |
2x (12-bit Resolution) |
| Peripheral Interfaces |
| USB OTG Ports |
2x |
| Serial Interfaces |
| SPI Ports |
1x |
| I2C Ports |
1x |
| I2S Audio Ports |
1x |
| Industrial Protocols |
| CAN Ports |
2x |
| Precision Time Protocol (PTP) |
Yes (Available via kernel update in downloads) |
| Networking |
| 10/100 Ethernet Ports |
2x |
| Physical |
| Operating Supply Voltage |
5 VDC to 28 VDC |
| Typical Power Consumption |
1.00 W |
| Fanless Temperature Range |
-40 °C to 85 °C |
| Width |
55.0 mm |
| Length |
74.9 mm |
| Radio Comms |
| Bluetooth |
Yes |
| WiFi Radio / Wireless LAN |
Yes |
| Solutions |
| TS-SILO Power Reserve (Super Capacitors) |
Yes |
| Software |
| Linux Kernel Version |
4.9 |
| Debian Linux |
Stretch (9.0) |
TS-8551 Block Diagram
(Download PDF version)
| Product Configuration |
| Part |
Description |
Price |
| TS-8551 |
TS-SOCKET Development Baseboard for TS-4100 & TS-4300 (System-on-Module not included)
|
Pricing
|
| Flash Media |
| Part |
Description |
Price |
| MSD-8GB-4100 |
TS-4100 bootable 8GB Class 10 microSD card including Arm tool chain, Debian Jessie Linux filesystem, documentation, and further binaries/utilities
|
$30
|
| MSD-8GB-USB-4100 |
TS-4100 bootable 8GB Class 10 microSD card including Arm tool chain, Debian Jessie Linux filesystem, documentation, and further binaries/utilities, includes USB reader
|
$63
|
| Accessories and Extras |
| Part |
Description |
Price |
| CN-TSSOCKET-M-10 |
Qty Ten (10) Male 100-Pin High Density Connectors for Custom Baseboard Design
|
$50
|
| CN-TSSOCKET-M-100 |
Qty One Hundred (100) Male 100-Pin High Density Connectors for Custom Baseboard Design
|
$322
|
| CB-USB-A-FEMALE-MICRO |
7" USB 2.0 Type-A Receptacle (Female) to Micro-B cable
|
$9
|
| CB-USB-A-MICRO-GOLD |
3' USB 2.0 Type-A to Micro-B cable
|
$9
|
| CB7-05 |
Null modem cable with a DB9F at each end
|
$10
|
| CB-JUMPER-10-F-F-6 |
Quantity 10 female-to-female 6-inch red jumper wires for use with 0.1" headers
|
$7
|
| CB-JUMPER-10-M-M-6 |
Quantity 10 male-to-male 6-inch blue jumper wires for use with 0.1" headers
|
$7
|
| Power Supplies |
| Part |
Description |
Price |
| PS-12VDC-REG-2_5AMP-3PB |
Regulated 12 VDC, 2.5 A wall mounted power supply with 3 pin black connector (100-240 VAC, 50-60 Hz, A-type Plug)
|
$21
|
| PS-5VDC-REG-2P1 |
Regulated 5 VDC, 2.5 A wall mounted power supply with 2 pin black screw terminal connector (100-240 VAC, 50-60 Hz, A-type Plug)
|
$26
|
| PS-12VDC-REG-BC |
International regulated 12VDC wall mounted power supply with barrel connector
|
$21
|
| Development Kits |
| Part |
Description |
Price |
| KIT-8551-4100 |
Development kit includes: TS-8551 baseboard; PS-12VDC-REG-2_5AMP-3PB power supply; CB-USB-A-MICRO-GOLD console and CB7-05 cables; MSD-8GB-USB-4100 removable boot media; and jumpers, jumper wires and other hardware
Includes packaged parts:
- TS-8551: TS-SOCKET Development Baseboard for TS-4100 & TS-4300 (System-on-Module not included)
- PS-12VDC-REG-2_5AMP-3PB: Regulated 12 VDC, 2.5 A wall mounted power supply with 3 pin black connector (100-240 VAC, 50-60 Hz, A-type Plug)
- CB-USB-A-MICRO-GOLD: 3' USB 2.0 Type-A to Micro-B cable
- CB7-05: Null modem cable with a DB9F at each end
- MSD-8GB-USB-4100: TS-4100 bootable 8GB Class 10 microSD card including Arm tool chain, Debian Jessie Linux filesystem, documentation, and further binaries/utilities, includes USB reader
- CB-JUMPER-10-F-F-6: Quantity 10 female-to-female 6-inch red jumper wires for use with 0.1" headers
- TS-KIT-BASE: Includes: 3-foot straight-through CAT5 cable; screwdriver; jumpers; rubber bumpers; standoffs; nuts and bolts
|
$257
|
