TS-TPC-8950-4900

Combination Product

10" High Performance Mountable Touch Panel Computer

Lifecycle: Fully Developed | Released: February 2016

With a large 10-inch touch panel screen and proven reliability, the TS-TPC-8950-4900 is a workhorse in the HMI and digital signage industries

  • Connected 10" Touch Panel PC with WiFi, Bluetooth, and Gigabit Ethernet
  • Robust Connectivity with USB, SATA II, PCIe, RS-485, CAN, DIO, and More
  • Accelerated 3D Graphics with i.MX6 Optimized Yocto Linux v3.10
  • Flexible Data Storage: High Reliability SLC or High Capacity MLC eMMC Flash
  • Rugged, Industrial Environment Ready with Fanless -20 °C to 70 °C Range
$776 (Qty. 100) $822 (Qty. 1)
No minimum order quantity on standard products.
Contact Sales Get Support Order Now
Manual Watch Video
Carrier Board
TS-TPC-8950 Thumbnail

TS-TPC-8950

Computer-on-Module
TS-4900 Thumbnail

TS-4900

With a large 10-inch touch panel screen and proven reliability, the TS-TPC-8950-4900 is a workhorse in the HMI and digital signage industries with the solo or quad core NXP i.MX6 with the Arm® Cortex®-A9 core. Asset tracking is also possible thanks to a mini-PCIe socket for cellular modem, and SIM card socket*. The TS-TPC-8950-4900 is capable of hardware-accelerated 3D graphics for eye-catching kiosks and has plenty of industry standard connectors and interfaces for control and data acquisition, including Gigabit Ethernet, WiFi, Bluetooth, RS-232, RS-485, CAN, SPI, I2C, and GPIO. The engine powering this solution is the TS-4900 System-on-Module, with high performance CPU, integrated WiFi and Bluetooth module, configurable eMMC flash (SLC or MLC), microSD socket, SATA II port, and PCI-e bus. Additional interfaces, such as UARTs, DIO, etc., are brought out on the TS-8950 baseboard via two 100-pin TS-SOCKET connectors. A 10-inch TFT SVGA resistive touch panel display with high brightness (320 nit) completes the solution.

The TS-TPC-8950-4900 is the bigger brother to the TS-TPC-8390-4900, running the same TS-4900 engine with a bigger screen and the addition of mSATA (quad core only), mini PCIe, XBee socket, PoE+, and SIM socket*. It's also an upgrade path for customers of the TS-TPC-8900-4700.

The TS-TPC-8950-4900 comes preloaded with Yocto Linux, which takes full advantage of the hardware accelerated graphics as well as other user space utilities to control DIO, SPI, and more to help jumpstart your development efforts. Other operating systems such as Android, and QNX are also available (Windows is not compatible with the TS-TPC-8950-4900). There's also a flexible choice of GUI frameworks including Qt, GTK, DirectFB, and more. Familiar GNU development tools, like gcc and gdb, are also installed, making on-board development easy. Cross compile toolchains are also available so you can develop using your favorite desktop IDE. Finally, as with most Linux distributions, other services like Apache Web Server, CGI-BIN, FTP, SSH, Telnet, Samba network services, etc. are available. An example CGI-BIN application has also been preloaded. Also included are user space utilities and applications to control DIO, SPI, and more so that you can get your product to market in record time.

As with all of our products, the source code, schematics, mechanical drawings, and manuals for the TS-TPC-8950-4900 are freely available for download in the resources tab. For the added peace of mind and confidence in our solution, a 45 day evaluation period, 1 year warranty, engineer-backed technical support, and 10+ year product availability are included with your purchase.

embeddedTS has partnered with a third-party vendor to provide anti-microbial, shock-absorbing, and super scratch-resistant film overlays. These films also protect screens from scratches, dirt, and abrasion. If interested, inquire with sales for more information and learn how to obtain a sample.

For more detailed information, please visit the System-on-Module and Baseboard links shown below.

* No cellular certifications included.

Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.
Arm and Cortex are registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere.

embeddedTS provides complete documentation for our mature products, including manuals, schematics, mechanical drawings, etc. The most recent documentation files are always made available through our website. If you don't find the documentation you are looking for, contact support for more information. Also, please make sure to visit our Embedded Systems Support webpage, and our official documentation.

Documentation
Certification
Software Download
Video
News Article
Block Diagram
Third Party Documentation
Featured On
From the Blog:
Product Notices:
Subscribe to the Product Communication System (TS-PCS) for TS-TPC-8950-4900 Notices
CPU
Architecture Arm
Part Number i.MX6
Vendor NXP
CPU Speed 1.1 GHz (Solo or Quad Core)
Floating Point Unit Yes
CPU Cores (Max) 4x
Core Specs
Base Memory Capacity 1 GB
Maximum Memory Capacity 2 GB (2 GB Standard on Quad)
Memory Type DDR3
FPGA 4 k LUT
Watchdog Timer 2x
Storage
Base Flash Capacity 4 GB (2 GB pSLC or 4 GB MLC)
Flash Type eMMC
microSD Card Socket 1x
SATA Ports 1x
Other
Battery-Backed Real Time Clock 1x
Graphics Processing Unit Yes
Sensors
Temperature Sensor 2x
General I/O
General-Purpose Input/Output (GPIO) Pins 8x
PWM Ports 3x
Serial Interfaces
RS-232 Ports 3x
RS-485 Ports 1x
RS-422 Ports 1x
SPI Ports 1x
I2C Ports 1x
I2S Audio Ports 1x
Peripheral Interfaces
USB Host Ports 3x
USB Device Ports 1x
USB OTG Ports 1x
PC/104 Ports 1x
PCI Express Bus 1x
Industrial Protocols
CAN Ports 1x
Networking
Gigabit Ethernet Ports 1x
10/100 Ethernet Ports 1x
Power-over-Ethernet Yes (PoE+)
Physical
Operating Supply Voltage 5 VDC to 30 VDC
Minimum Power Consumption 0.50 W (Quad: 0.9 W)
Typical Power Consumption 1.30 W (Quad: 2.0 W)
Maximum Power Consumption 10.00 W
Fanless Temperature Range -20 °C to 70 °C
Width 284.0 mm
Length 51.0 mm
Height 218.0 mm
Software
Preloaded Software Yocto
Ubuntu Core 16.00
Linux Kernel Version 3.10
Debian Linux Stretch (9.0)
Windows OS Embedded Compact 2013
Android OS 4.4.3 KitKat
Yocto Linux 2.2 Morty
QNX Neutrino RTOS Neutrino RTOS (Available on Quad Core Only)
Graphics / HMI
Screen Diagonal Size 10"
Touchscreen Yes
Screen Resolution 800x600
Speaker Yes
Touchscreen Type Resistive
Radio Comms
Cellular Modem Yes
Quantities
Product Configurations 1 10 25 50 100
TS-4900-1024-S10S-C $203 $176 $171 $164 $157
TS-4900-1024-4096F-S8S-RTC-I $233 $208 $200 $190 $184
TS-4900-1024-4096F-S8S-RTC-WIFI-I $279 $254 $243 $232 $221
TS-4900-2048-4096F-Q10S-RTC-E $308 $283 $272 $260 $248
TS-4900-2048-4096F-Q10S-RTC-WIFI-E $354 $327 $315 $301 $287
TS-TPC-8950 $619 $619 $619 $619 $619
TS-TPC-8950-DEV $697 $697 $697 $697 $697
TS-4900-S-CORE-I $279 $254 $243 $232 $221
TS-4900-Q-CORE-E $354 $327 $315 $301 $287
Product Configuration
Part Description Price
TS-4900-1024-S10S-C TS-4900 commercial grade (0 °C to 70 °C) System-on-Module with Solo 1GHz i.MX6 CPU and 1GB RAM (SD card required to boot sold separately) Pricing
TS-4900-1024-4096F-S8S-RTC-I TS-4900 industrial grade (-40 °C to 85 °C) System-on-Module with Solo 800MHz i.MX6 CPU, 1GB RAM, 4GB eMMC Flash with Linux and RTC Pricing
TS-4900-1024-4096F-S8S-RTC-WIFI-I TS-4900 industrial grade (-40 °C to 85 °C) System-on-Module with Solo 800MHz i.MX6 CPU, 1GB RAM, 4GB eMMC Flash with Linux, RTC and on-board WiFi & Bluetooth module Pricing
TS-4900-2048-4096F-Q10S-RTC-E TS-4900 extended temp. grade (-20 °C to 70 °C) System-on-Module with Quad 1GHz i.MX6 CPU, 2GB RAM, 4GB eMMC Flash with Linux and RTC Pricing
TS-4900-2048-4096F-Q10S-RTC-WIFI-E TS-4900 extended temp. grade (-20 °C to 70 °C) System-on-Module with Quad 1GHz i.MX6 CPU, 2GB RAM, 4GB eMMC Flash with Linux, RTC and on-board WiFi & Bluetooth module Pricing
TS-TPC-8950 Open mountable frame 10" touch panel computer (system-on-module not included) Pricing
TS-TPC-8950-DEV Open mountable frame 10" touch panel computer (system-on-module not included) with accelerometer, mini-PCIe/mSATA slot with SIM card Pricing
Software Specific Product Configuration
Part Description Price
TS-4900-S-CORE-I TS-4900-1024-4096F-S8S-RTC-WIFI-I with Ubuntu Core, SoM with solo 800MHz i.MX6 CPU, 1GB RAM, 4GB eMMC flash, RTC and on-board WiFi/BT module (-40C to 85C) Pricing
TS-4900-Q-CORE-E TS-4900-2048-4096F-Q10S-RTC-WIFI-E with Ubuntu Core, SoM with quad 1GHz i.MX6 CPU, 2GB RAM, 4GB eMMC flash, RTC and on-board WiFi/BT module (-20C to 70C) Pricing
Flash Media
Part Description Price
MSD-8GB-CLASS10-4900 TS-4900 bootable 8GB Class 10 microSD card with Yocto Linux filesystem and further binaries/utilities $30
MSD-8GB-CLASS10-USB-4900 TS-4900 bootable 8GB Class 10 microSD card pre-loaded with Debian, includes USB reader $63
MSD-8GB-BLANK 8GB Class 10 microSD card $30
Accessories and Extras
Part Description Price
CB-JUMPER-10-F-F-6 Quantity 10 female-to-female 6-inch red jumper wires for use with 0.1” headers $7
HS-21x21x15 CPU heatsink measuring 21x21x15mm recommended for i.MX6 quad core $19
RC-DB9 10-pin header COM port adapter cable to DB-9 $5
CB-USB-A-FEMALE-MICRO 7" USB 2.0 Type-A Receptacle (Female) to Micro-B cable $9
LCD10-STAND Desktop metal support to mount a 10-inch TFT-LCD panel $69
CB-USB-A-MICRO-GOLD 7" USB 2.0 Type-A to Micro-B cable $9
Power Supplies
Part Description Price
PS-12VDC-REG-2_5AMP-3PB Regulated 12 VDC, 2.5 A wall mounted power supply with 3 pin black connector (100-240 VAC, 50-60 Hz, A-type Plug) $21
Development Kits
Part Description Price
KIT-8950-4900 Development kit including suggested parts for new development. Includes packaged parts:
  • MSD-8GB-CLASS10-USB-4900: TS-4900 bootable 8GB Class 10 microSD card pre-loaded with Debian, includes USB reader
  • RC-DB9: 10-pin header COM port adapter cable to DB-9
  • CB7-05: Null modem cable with a DB9F at each end
  • CB-USB-A-MICRO-GOLD: 7" USB 2.0 Type-A to Micro-B cable
  • PS-12VDC-REG-2_5AMP-3PB: Regulated 12 VDC, 2.5 A wall mounted power supply with 3 pin black connector (100-240 VAC, 50-60 Hz, A-type Plug)
 $102
